Electronics Bench
Our Electronics Bench features:
Our Electronics Bench...
is the heart of the shop – and it shows in our logo! From soldering irons to our new bench power supply and every capacitor in between, you can be sure to find what you need to work on your next electronics project at HackPGH!
Major Equipment:
Our electronics bench can bring your projects to light!
Two Hakko FX-888D Soldering Stations
Description: FX-888Ds are soldering stations with features like a digital display, adjustable temperature control, and preset temperature storage. It offers a wide temperature range and is designed to be both ergonomic and ESD-safe.
Additional Soldering Equipment
Featuring: Ten individual Soldering Irons, and One Desoldering Station.
Siglent SPD3303X-E Bench Power Supply
Features: 220w, Three independent and isolated outputs, programmable with remote programs supported, LCD display.
Siglent SDS824X HD Digital Oscilloscope
Description: Our (DSO) is used to measure, display, and analyze electrical signals. It captures, stores, and analyzes waveforms.I t can also decode serial buses and perform power analyses.
Features:
4 analog channels
- 16 digital channels
- 200 MHz bandwidth models
- 12-bit high resolution
- Real-time sampling rate up to 2 GSa/s
- Memory depth up to 100 Mpts
- Waveform capture rate up to 500,000 wfm/s (Sequence mode)
- 7-inch touch screen, support for external mouse and keyboard
Staco Variac Variable Autotransformer
Power Rating 3 kVA
Model: 3PN1010
Power type: AC to AC
AC voltage rating: 120v
Conversion function: step-down, step-up
SDG2082X Siglent Arbitrary Waveform Generator
Description: The SDG2082X is a series of dual-channel function arbitrary waveform generator that can produce a wide variety of signals, including standard waveforms like sine, square, and ramp, as well as custom arbitrary waveforms
Features:
- Dual-channel, 120MHz maximum bandwidth, 20Vpp maximum output amplitude, high fidelity output with 80dB dynamic range
- High-performance sampling system with 1.2GSa/s sampling rate and 16-bit vertical resolution. No detail in waveforms will be lost
- TrueArb technology, based on a point-by-point architecture, supports any 8pts~8Mpts Arb waveform with a sampling rate in range of 1μSa/s~75MSa/s
- EasyPulse technology, capable of generating lower jitter Square or Pulse waveforms, brings a wide range and extremely high precision in pulse width and rise/fall times adjustment
- Analog and digital modulation types: AM, DSB-AM, FM, PM, FSK, ASK and PWM
- Sweep and Burst function
- High precision Frequency Counter
Interfaces:
- USB Device
- USB Host
- LAN
- VXI-11, support U Disk storage and software
Display: 4.3” touch screen display for easier operation
Rework Equipment
Hakko 852 hot air rework station
Description:
Features:
Built in vacuum pick-up:
- Two modes of operation
- Manual: Simple operation
- Auto: Programmable process control
- Digital temperature display
- Digital hot air dwell time display
- Airflow meter
- Self-contained air source
- Auto cool-down mode for safety
Additional Equipment
Multimeters of various capabilities
Hand crimper kit
Wire-wrapping tools
Various meters (temperature and capacity)
